Corrosion resistant alloy

nickel alloy

Corrosion resistant alloy

Corrosion resistant alloys are a class of metal materials with excellent resistance to corrosion, and they exhibit superior properties in a variety of environments. These materials are usually divided into several categories such as iron-based alloys, nickel-based alloys and active metals.

✚ Location:Home >> Products >> nickel alloy
alloy steel price

Corrosion resistant alloy

Product characteristics:
Standard : AMS/ASTM/JIS/BS/ISO
Thickness : 0.3mm-7.9mm
Width : customized Max.width 3000mm
Length : Customized
Service hotline:+8613964085002
Get a quote Contact immediately
Product details


Parameter


Product Name

Corrosion and rust resistant universal application magnesium az31b alloys

Standard

AMS/ASTM/JIS/BS/ISO

Brand

AZ31B/ZK60A/AZ91D/AZ61A/AZ40M/AZ80A

Thickness

0.3mm-7.9mm

Width

customized Max.width 3000mm

Length

Customized

Application

transportation (automobiles, motorcycles, bicycles, rail transit, aviation); electronic products (computers, mobile phones, digital cameras, etc.); medical equipment

 (wheelchairs, crutches, rehabilitation fitness equipment, etc.) aerospace; textile High standards and diversified demands in the fields of printing machinery and automobiles.

Lead time

3 to 25 working days

Packing

Wooden pallet or according to customer's request



Specification of magnesium alloy:

Magnesium Alloy Plates/sheet

classify

specification

Brand

AZ31B/ZK60A/AZ91D/AZ61A/AZ40M/AZ41M/AZ80A

Sheet

Thickness:0.3-7.9mm Customized Max.width 600mm

Medium and heavy plate

Thickness:8-15mm Customized Max.width 1500mm

Thick plate

Thickness:15-200mm Customized Max.width 3000mm

Magnesium Alloy Bar/Rod

Brand

AZ31B/ZK60A/AZ91D/AZ61A/AZ40M/AZ41M/AZ80A/Mg99.95

Extrusion Bar

φ3-φ130*3000(Customized)

Extrusion Bar

φ93-φ600*4500(Customized)

Magnesium alloy profiles

Size

Customized


Chemical Composition Of Magnesium Alloy Plate/Sheet


ASTM B107/B107-13
ASTM B93/B93M

AZ31B

ZK60A

AZ61A

AZ80A

Al %

2.50-3.50

--------

5.80-7.20

7.80-9.20

Ca %

0.04max

--------

--------

--------

Mn %

0.20-1.00

--------

0.15-0.50

0.12-0.50

Cu %

0.01max

--------

0.05max

0.05max

Fe %

0.005max

--------

0.005max

0.005max

Si %

0.10max

--------

0.10max

0.10max

Zn %

0.60-1.40

4.8-6.2

0.40-1.50

0.20-0.80

Ni %

0.005max

--------

0.005max

0.005max

Others each %

--------

--------

--------

--------

Others each %

0.30max

0.30max

0.30max

0.30max

Mg

BALANCE

BALANCE

BALANCE

BALANCE


tensile requirements Of Magnesium Alloy Plate/Sheet


Magnesium Alloy

Mechanical Property

Application

ASTM

tensile strength(N/MM2)

Yield strength(N/mm)

Elongation

--

AZ31B

230~290

170~210

10~24

Standard extrusion alloy

AZ61A

270~390

190~240

9~15

High strength extrusion alloy

AZ80A

330~360

230~250

8~10

High strength extrusion alloy


Description


Corrosion resistant alloys are a class of metal materials with excellent resistance to corrosion, and they exhibit superior properties in a variety of environments. These materials are usually divided into several categories such as iron-based alloys, nickel-based alloys and active metals.


Among iron-based alloys, corrosion resistant stainless steel is widely used because of its excellent corrosion resistance. This type of alloy uses iron as the main element, and other elements such as chromium and nickel are added to improve its corrosion resistance.


Nickel-based corrosion resistant alloys, such as Hastelloy and Ni-Cu alloys, exhibit excellent corrosion resistance due to their special chemical composition and structure. Nickel (Ni), as a metal with a face-centered cubic structure, has extremely high stability and can be integrated into more alloying elements, such as chromium (Cr), molybdenum (Mo), aluminum (Al), etc., thus providing protection in a variety of harsh environments. Nickel itself has a strong resistance to stress corrosion caused by chloride ions, especially in strong reducing environments, complex mixed acid environments and solutions containing halogen ions, nickel-based alloys far exceed the performance of iron based stainless steel.


Active metals, such as titanium (Ti), zirconium (Zr), tantalum (Ta), etc., also show good corrosion resistance. Titanium is a typical representative, it plays an important role in many stainless steel can not be competent corrosion environment. The corrosion resistance of titanium stems from its dense oxide film formed in an oxidizing atmosphere, but this also means that it is not suitable for use in corrosive environments with strong reducibility or high sealing, and at the same time, the application temperature of titanium is usually limited to less than 300 degrees Celsius. It should be noted that active metals are not suitable for fluorine-containing environments, such as hydrofluoric acid environments, in which case materials such as Hastelloy C2000 or NiCu alloys can be selected.


Corrosion resistant alloy composite pipe is an innovative metal composite consisting of two different metal materials that are tightly bound together by various deformation and joining techniques. The design principle of this composite pipe is to make the base to meet the allowable stress of the pipe design, and the composite layer is responsible for resisting corrosion. Corrosion resistant alloy composite pipe combines all the advantages of base and lamination, which not only effectively reduces costs, but also provides excellent safety and reliability in chloride and acidic environments. With the development of industrial technology and the complexity of environmental media, the production technology of corrosion-resistant alloy composite pipes has developed rapidly, providing metal pipes with higher comprehensive performance for many industries. They can maximize the complementary advantages of materials, save alloy materials, reduce engineering costs, and at the same time, on the basis of ensuring the performance of the base pipe, significantly improve the corrosion resistance of the pipe, extend the service life, and become an ideal substitute for pure stainless steel pipe, copper pipe or other corrosion resistant alloy pipe.
